FR08160 Esd grid box with movable baffle

ESD Grid Box with Movable Baffle – Detailed Overview

An ESD Grid Box with a Movable Baffle is a specialized storage and transportation solution for static-sensitive electronic components. It provides flexibility in compartment sizing while maintaining electrostatic protection, making it ideal for use in electronics manufacturing, assembly lines, repair stations, and cleanroom environments.

Key Components & Features

1. ESD-Safe Material

• Made from conductive or dissipative plastic, typically carbon-filled polypropylene or ABS.
• Surface resistance of 10⁴ to 10⁹ ohms (for dissipative) or 10³ ohms or lower (for conductive).
• Prevents static charge accumulation and safely dissipates any charge to ground.

2. Grid Design

• Pre-molded grid pattern allows for customizable compartments.
• Ensures ventilation and weight reduction while maintaining structure.
• Can accommodate various electronic components, tools, and PCBs.

3. Movable Baffle (Adjustable Dividers)

• Interlocking dividers that can be repositioned within the grid.
• Allows custom compartment sizes based on the shape and size of the components.
• Made from the same ESD-safe material to maintain static protection.

4. Stackability & Compatibility

• Designed for easy stacking with interlocking features to ensure stability.
• Some models are compatible with ESD-safe lids or conductive foam inserts for added protection.

5. Optional Features

• Lids (snap-on or hinged) for additional protection.
• Foam inserts for delicate components.
• Label slots for easy identification.
• Handles for better portability.

Applications

1. Electronics Manufacturing & Assembly

• Storing and organizing ICs, PCBs, capacitors, resistors, and connectors.
• Reducing damage from ESD in assembly lines and workstations.

2. Storage & Transportation

• Moving sensitive parts within an EPA (Electrostatic Protected Area).
• Shipping static-sensitive components without the need for excessive protective packaging.

3. Repair & Testing Labs

• Organizing small parts for easy access and reconfiguration.
• Keeping repair and testing tools free from static damage.

Selection Guide – What to Consider

Recommended ESD Grid Boxes with Movable Baffles

Here are some popular brands and suppliers that manufacture ESD-safe grid boxes with adjustable dividers:

1. Conductive Containers, Inc.
2. Bins & Things ESD-Safe Boxes
3. Metro ESD Grid Bins
4. Treston ESD Component Bins
5. 3M ESD Storage Solutions
